Derinding/Cutting ASB 460/560/770

The ASB 460, ASB 560, and ASB 770 are premium derinding machines, offering cutting-edge technology and superior quality for efficient meat processing. Designed for high-capacity operations, these machines ensure precise cuts, maximum yield, and minimal rework, making them essential tools for industrial-scale meat processors.

Key Features:
Innovative Cutting Technology:
Equipped with automatic initial cut control and a spring-mounted slicing system, the ASB series delivers clean, precise cuts for optimal product yield.
Versatile Cutting Widths:
Choose from cutting widths of 460 mm (ASB 460), 560 mm (ASB 560), or 770 mm (ASB 770) to suit your processing requirements.
Adjustable Slicing Thickness:
Standard slicing thickness ranges from 0–4 mm, with optional settings for 4–8 mm, 6–10 mm, and 8–12 mm for enhanced flexibility.
High Efficiency:
Fully automated product throughput and minimal rework reduce labor costs while ensuring high output.
Hygienic Design:
Includes a standard cleaning program for quick, resource-efficient maintenance, meeting the highest hygiene standards.
Robust Construction:
Built with an extremely durable machine stand, wear-resistant components, and a strong drive system for long-term reliability.
Flexible Operation:
Operable from the left (optional) or right, and can be suspended over a shredding belt for customized workflows.

Applications:
Derinding various meat cuts efficiently with minimal waste

The ASB 460, ASB 560, and ASB 770 combine robust construction, advanced technology, and user-friendly operation to deliver exceptional derinding performance. Whether you require compact solutions or wide-format cutting, the ASB series ensures precision, efficiency, and high yields, making it a reliable choice for professional meat processors.

Technical Specifications:
ASB 460:
Motor Output: 1.1 kW
Cutting Width: 460 mm
Cutting Thickness: 0–4 mm (Optional: 4–8 mm, 6–10 mm, 8–12 mm)
Dimensions (W x H x L): 915 x 1287 x 900 mm (1750 mm with conveyor)
Net Weight: 370 kg
Power Connection: 400 V / 50 Hz / 16 A

ASB 560:
Motor Output: 1.1 kW
Cutting Width: 560 mm
Cutting Thickness: 0–4 mm (Optional: 4–8 mm, 6–10 mm, 8–12 mm)
Dimensions (W x H x L): 1021 x 1287 x 900 mm (2055 mm with conveyor)
Net Weight: 400 kg
Power Connection: 400 V / 50 Hz / 16 A

ASB 770:
Motor Output: 1.5 kW
Cutting Width: 770 mm
Cutting Thickness: 0–4 mm (Optional: 4–8 mm, 6–10 mm, 8–12 mm)
Dimensions (W x H x L): 1230 x 1287 x 900 mm (2055 mm with conveyor)
Net Weight: 435 kg
Power Connection: 400 V / 50 Hz / 16 A
