The Jarvis Model 1000-FS is a high-performance hydraulic breaking saw engineered for precision and durability in beef and pork processing applications. With an adjustable cut depth range from 3 to 6 inches (76 to 152 mm), the 1000-FS provides unmatched versatility and accuracy. Designed for high-volume operations, it effortlessly handles beef chucks, shoulders, ribs, forequarters, chine bones, briskets, loins, aitch bones, and pork chine bones and ham marking.

Key Features:
Powerful Hydraulic Motor:
A 4 hp high-powered hydraulic motor ensures no bogging down, no motor icing, low noise, and instant stopping for seamless performance.
Adjustable Cut Depth Stop Gauge:
Provides precise control with a depth range of 3 to 6 inches, ensuring consistent and accurate cuts for various processing needs.
Operator-Friendly Design:
Lightweight and ergonomically designed with a direct-drive motor to reduce vibration and provide easy handling and comfort.
Enhanced Safety:
Equipped with anti-tie down controls to ensure operator protection and compliance with stringent safety regulations.
Corrosion-Resistant Construction:
Built from high-quality materials to maintain optimal hygiene and withstand the demands of industrial meat processing.

The Jarvis 1000-FS Hydraulic Breaking Saw is the ultimate solution for meat processing facilities looking for precision, power, and durability. Its innovative design, superior safety features, and adjustable cutting capabilities make it an essential tool for achieving high-quality processing results with efficiency and ease.

Technical Specifications:
Drive
Hydraulic

Operating Parameters
Motor Power:
7 hp (5220 W)
Blade Speed:
2150 rpm (7.6 gpm or 28.8 Lpm)
Control Handles:
Dual Anti-tie Down (Electric or Air)

Blade Diameters
9.0 in (229 mm)
10.5 in (267 mm)
12.0 in (305 mm)
15.0 in (380 mm)

Cutting Depth (Maximum)
With 9 in / 229 mm Blade:
3.0 in (76 mm)
With 10.5 in / 267 mm Blade:
3.75 in (95 mm)
With 12 in / 305 mm Blade:
4.5 in (114 mm)
With 15 in / 381 mm Blade:
6.0 in (152 mm)

Dimensions and Weight
Overall Length (with 15 in Blade):
27.5 in (699 mm)
Weight:
41 lbs (18.6 kg)

Hydraulic Power Unit Specifications
Motor Power:
10 hp (7457 W)
Operating Voltage:
460 / 230 V, 3 phase, 60 Hz (other voltages and 50 Hz available)
Hose Length:
16 ft (5 m)
Flow Rate:
7.6 gal/min (28.8 L/min)
Oil Capacity:
30 gal (114 L)
Overall Dimensions (l x w x h):
38 x 31.4 x 32.5 in (965 x 798 x 826 mm)
Weight (without oil):
400 lbs (181 kg)

Equipment Selection and Accessories
Model 1000-FS Configurations
Standard Models (with blade and guard)
9 in / 229 mm Blade – Order Number: 4007006
10.5 in / 267 mm Blade – Order Number: 4007008
12 in / 305 mm Blade – Order Number: 4007008
Chine Bone Models
9 in / 229 mm Chine Bone – Order Number: 4007021
9 in / 229 mm Chine Bone, Left Side – Order Number: 4007033
10.5 in / 267 mm Chine Bone – Order Number: 4007022
10.5 in / 267 mm Chine Bone, Left Side – Order Number: 4007041
Adjustable Handle Models
10.5 in / 267 mm Adjustable Handles – Order Number: 4007049
12 in / 305 mm Adjustable Handles – Order Number: 4007050
12 in / 305 mm Adjustable Handles, Left Side – Order Number: 4007040

Heavy Duty (HD) Models
15 in / 380 mm Blade, Electric Triggers – Order Number: 4007062
15 in / 380 mm Blade, Air Triggers – Order Number: 4007065
9 in / 229 mm Blade, Air Triggers – Order Number: 4007069

Hydraulic Power Unit
460 / 230 V, 3 phase, 60 Hz – Order Number: 4027042
Air Triggers, 50 Hz – Order Number: 4027321

Blades (by Size and Type)
9.0 in / 229 mm Blade, 72 teeth – Order Number: 1023102
9.0 in / 229 mm Blade, 130 teeth – Order Number: 1023100
9.0 in / 229 mm Blade, Noise Reduction – Order Number: 1023128
10.5 in / 267 mm Blade, 84 teeth – Order Number: 1023111
12.0 in / 305 mm Blade, 72 teeth – Order Number: 1023112
15 in / 381 mm Blade, Noise Reduction – Order Number: 1023614

Accessories
Balancer – Order Number: 4042035
