Model 30CL-1 Hydraulic Hock and Horn Cutter

C$0.00

Excluding GST/HST

Quantity

The Jarvis Model 30CL-1 is a high-performance, hydraulically powered tool engineered for efficient cutting of fore and hind beef hocks through bone or joint. It also serves as a reliable beef dehorner, making it an essential tool for demanding meat processing operations. With its rapid 1.5-second cutting cycle and robust construction, the 30CL-1 enhances productivity while prioritizing operator safety.

Key Features:

High Cutting Force:

Delivers an impressive 9,900 lb-f (44 kN) cutting force, ensuring clean, precise cuts every time.

Quick Cutting Cycle:

Features a 1.5-second cycle, designed for high-production environments to maximize efficiency.

Advanced Safety Features:

Equipped with anti-tie-down controls, dual control triggers, and additional safety guards, including pinch point, thumb, and trigger guards for operator protection.

Durable Construction:

Built with virtually all stainless steel for superior durability, hygiene, and corrosion resistance, meeting national and international safety standards.

The Jarvis 30CL-1 Beef Hock Cutter combines cutting-edge performance with advanced safety features, delivering unmatched efficiency and reliability for high-demand meat processing operations. Designed to meet the toughest standards, this hydraulic tool ensures clean, rapid cuts while prioritizing hygiene and operator safety.

Technical Specifications:

Model: 30CL-1
Drive: Hydraulic
Cutting Force: 9900 lb-f / 44 kN
Cutting Cycle Time: 1.5 sec
Control Handles: Air / Dual Anti-tie Down, 50 psi / 3.4 bar
Blade Opening:
- At Tips: 4.0 in / 102 mm
- Widest: 5.75 in / 146 mm
Overall Length: 32 in / 813 mm
Weight: 38 lbs / 17.2 kg

Hydraulic Power Unit Specifications

Motor Power:
- Single Tool: 5 hp / 3728 W
- Two Tools: 10 hp / 7457 W
Operating Voltage: 460 / 230 V, 3 phase, 60 Hz (Other voltages and 50 Hz available)
Hose Length: 16 ft / 4.9 m
Oil Capacity:
- 20 gal / 76 L
- 30 gal / 114 L
Oil Viscosity: 200 SUS / 46 ISO at 100°F / 40°C

Dimensions and Weight

Overall Dimensions:
- Model 4027266: 32 x 25 x 30 in / 813 x 635 x 762 mm
- Model 4027201: 39 x 35.4 x 34 in / 991 x 899 x 864 mm
Weight:
- Model 4027266: 250 lbs / 113 kg
- Model 4027201: 500 lbs / 227 kg

Model Variations

Hock Cutter (Standard): Order Number: 4025013
Hock Cutter with Pistol Grip Handle: Order Number: 4025063
Hock Cutter with Grabber: Order Number: 4025095
Sheep Head Dropper: Order Number: 4025101

Power Units

Single Tool (Includes Hydraulic and Control Hoses):
- 460 / 230 V, 3 phase, 60 Hz – Order Number: 4027266
Two Tools (Includes Hydraulic and Control Hoses):
- 460 / 230 V, 3 phase, 60 Hz – Order Number: 4027201
