Model JC3A - Pneumatic Dehider

The Jarvis JC IIIA is a pneumatically powered dehider engineered for top-tier performance in cattle, veal, hog, and sheep skinning operations. Renowned as the leading tool worldwide for hide removal, the JC IIIA delivers unmatched skinning precision—producing the highest quality hides with no cuts, marks, or holes. Its extra-thin stainless steel head and lightweight design ensure exceptional handling, making it a top choice for demanding processing environments.

Powered by a super-efficient motor, the JC IIIA operates at just 12 ft³/min at 45 psi (0.34 m³/min at 3.1 bar), reducing air consumption while delivering 6500–7000 oscillations per minute for smooth and accurate skinning. Weighing only 2.9 lbs (1.3 kg), it offers reduced operator fatigue and long-lasting durability with minimal maintenance—ideal for high-volume meat processing operations.
4o

Key Features:
Exceptional Hide Quality:
Skins perfectly, leaving no cuts, marks, or holes for the highest possible hide quality.
High Efficiency:
Features a super-efficient motor design, consuming only 12 ft³/min at 45 psi (0.34 m³/min at 3.1 bar).
Lightweight Design:
Weighs only 2.9 lbs (1.3 kg), making it easy to handle and reducing operator fatigue.
Extra-Thin Head:
Equipped with a stainless steel center plate for enhanced handling, strength, and durability.
High Capacity, Long Life:
Designed for high performance, long-lasting use, and low maintenance in demanding processing environments.

The Jarvis JC IIIA Dehider sets the standard for efficiency, precision, and durability in skinning tools. Its lightweight, high-performance design makes it the top choice for producing flawless hides in cattle, veal, hog, and sheep processing operations.

Technical Specifications:
Drive: Pneumatic
Motor Power: 0.55 hp (410 W)
Operating Pressures:
45 psi (3.1 bar)
90 psi (6.2 bar)
Air Consumption: 12 ft³/min (0.34 m³/min)
Blade Speed (Oscillations): 6500 - 7000 / min
Control Handle: Single Trigger, Pneumatic
Blade Diameters:
3.9 in (99 mm)
4.3 in (109 mm)
Overall Length: 13 in (330 mm)
Weight: 2.9 lbs (1.3 kg)

Equipment Selection
Model JC IIIA Configurations
45 psi (3.1 bar) Configurations:
With 3.9 in / 99 mm blades – Order Number: 4034035
With 4.3 in / 109 mm blades – Order Number: 4034036
With 3.9 in / 99 mm RT blades – Order Number: 4034050
With 4.3 in / 109 mm RT blades – Order Number: 4034049
With 4.3 in / 109 mm blades (Round Runner) – Order Number: 4034052
90 psi (6.2 bar) Configurations:
With 3.9 in / 99 mm blades – Order Number: 4034037
With 4.3 in / 109 mm blades – Order Number: 4034038
With 3.9 in / 99 mm RT blades – Order Number: 4034042
With 4.3 in / 109 mm RT blades – Order Number: 4034041

Accessories
Air System Components
Air Hose (16 ft / 4.9 m)
Order Number: 1059002
Air Filter / Regulator / Lubricator
Order Number: 3022003

Support Components
Suspension Bracket
Order Number: 1042028

Replacement Blades
Standard Blades (1 Pair):
3.9 in / 99 mm Diameter Blades – Order Number: 3023004
4.3 in / 109 mm Diameter Blades – Order Number: 3023011
Round Teeth Blades:
3.9 in / 99 mm Diameter – Order Number: 3023162
4.3 in / 109 mm Diameter – Order Number: 3023163

Lubrication Supplies
Air Mist Oil:
1 pt / 0.5 L – Order Number: 1062010
1 gal / 3.8 L – Order Number: 1062011
5 gal / 18.9 L – Order Number: 1062012
Jarvis Food Grade Lubricant:
1 lb / 0.45 kg – Order Number: 1062003
35 lbs / 15.9 kg – Order Number: 1062005

Additional Accessories
Vibration Tachometer
Order Number: 8012004
Tool Kit
Order Number: 8039085
